INTRODUCTION:

Model	Diagonal Size	Pixel Format	Luminance	Interface	Viewing Angle	Operating Temperature range
TV070WVM-NW0	7.0 inch	800(RGB)x480	850 cd/m2	RGB	85/85/85/85	-30 ~ 85 °C
TT102WSB-NW0	10.1 inch	1024(RGB)x600	-	LVDS	80/80/60/70	-20 ~ 70 °C
BA104S01-100	10.4 inch	800(RGB)x600	500 cd/m2	LVDS	70/70/60/70	-20 ~ 70 °C
BA104S01-200	10.4 inch	800(RGB)x600	300 cd/m2	LVDS	70/70/60/70	-20 ~ 70 °C
TT121S0M-NW0	12.1 inch	800(RGB)x600	450 cd/m2	LVDS	80/80/65/75	-20 ~ 70 °C
AV123Z7M-N11	12.3 inch	1920(RGB)x720	800 cd/m2	LVDS	80/80/80/80	-30 ~ 85 °C
HM150X01-102	15.0 inch	1024(RGB)x768	300 cd/m2	LVDS	80/80/70/60	0 ~ 60 °C
HT185WX1-300	18.5 inch	1366(RGB)x768	250 cd/m2	LVDS	85/85/80/80	0 ~ 50 °C
HT185WX1-400	18.5 inch	1366(RGB)x768	200 cd/m2	LVDS	85/85/80/80	0 ~ 50 °C
