Tianma
- Product description：
INTRODUCTION:
| Model | Diagonal Size | Pixel Format | Luminance | Interface | Viewing Angle | Operating Temperature range |
| TM020GDH43-00 | 2.0 inch | 176(RGB)x220 | 220 cd/m² |
CPU |
70/70/70/60 | -20 ~ 70 °C |
| TM022HDHT11-00 | 2.2 inch | 240(RGB)x320 | 90 cd/m² |
RGB |
40/45/48/45 | -20 ~ 70 °C |
| TM023KDZ32-03 | 2.3 inch | 320(RGB)x240 | 320 cd/m² |
CPU |
55/55/60/45 | -20 ~ 70 °C |
| TM024HDH49-00 | 2.4 inch | 240(RGB)x320 | 200 cd/m² |
CPU |
70/70/70/60 | -20 ~ 70 °C |
| TM024HDHG20-00 | 2.4 inch | 240(RGB)x320 | 350 cd/m² |
- |
- | -20 ~ 70 °C |
| TM027CDH14-00 | 2.7 inch | 320(RGB)x240 | 250 cd/m² |
RGB/CCIR656/601/YUV |
60/70/70/70 | -20 ~ 70 °C |
| TM028HBHG55-00 | 2.8 inch | 240(RGB)x320 | 250 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM028HDHG59-01 | 2.8 inch | 240(RGB)x320 | 300 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM030LDHT1-00 | 3.0 inch | 240(RGB)x400 | 130 cd/m² |
CPU/RGB/SPI |
40/45/55/40 | -20 ~ 70 °C |
| TM035KBH02-09 | 3.5 inch | 320(RGB)x240 | 350 cd/m² |
RGB/CCIR601/656 |
70/70/60/70 | -20 ~ 60 °C |
| TM035KDH03-79 | 3.5 inch | 320(RGB)x240 | 300 cd/m² |
RGB/CCIR601/656 |
70/70/60/70 | -20 ~ 70 °C |
| TM035KDH04-09 | 3.5 inch | 320(RGB)x240 | 650 cd/m² |
RGB/CCIR601/656 |
70/70/60/70 | -20 ~ 70 °C |
| TM035KVHG01-09 | 3.5 inch | 320(RGB)x240 | 400 cd/m² |
RGB/CCIR601/656 |
70/70/60/70 | -20 ~ 70 °C |
| TM035PDHG03-00 | 3.5 inch | 320(RGB)x480 | 250 cd/m² |
CPU/RGB/SPI |
70/70/70/60 | -20 ~ 70 °C |
| TM035WDHG03-00 | 3.5 inch | 480(RGB)x640 | 350 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM037WBHT01-00 | 3.7 inch | 480(RGB)x640 | 155 cd/m² |
RGB |
45/50/80/40 | -20 ~ 70 °C |
| TM037WDHT01-00 | 3.7 inch | 480(RGB)x640 | 200 cd/m² |
CMOS |
80/40/45/50 | -20 ~ 70 °C |
| TM040YDHG32-00 | 4.0 inch | 480(RGB)x800 | 550 cd/m² |
MIPI |
80/80/80/80 | -20 ~ 70 °C |
| TM043NBH02-40 | 4.3 inch | 480(RGB)x272 | 300 cd/m² |
RGB |
70/70/70/50 | -20 ~ 70 °C |
| TM043NBHG04-00 | 4.3 inch | 480(RGB)x272 | 800 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM043NDH02-40 | 4.3 inch | 480(RGB)x272 | 400 cd/m² |
RGB |
75/75/75/55 | -20 ~ 70 °C |
| TM043NDHG11-00 | 4.3 inch | 480(RGB)x272 | 880 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM043NDHG12-00 | 4.3 inch | 480(RGB)x272 | 270 cd/m² |
RGB |
70/70/50/70 | -20 ~ 80 °C |
| TM043NVHG08-00 | 4.3 inch | 480(RGB)x272 | 350 cd/m² |
RGB |
80/80/80/60 | -30 ~ 85 °C |
| TM043YDHG30-40 | 4.3 inch | 480(RGB)x800 | 300 cd/m² |
RGB |
85/85/85/85 | -20 ~ 70 °C |
| TM043YVHG35-00 | 4.3 inch | 480(RGB)x800 | 300 cd/m² |
RGB |
80/80/80/80 | -20 ~ 70 °C |
| TM046JDHP01-30 | 4.66 inch | 720(RGB)x1280 | 400 cd/m² |
MIPI |
85/85/85/85 | -20 ~ 70 °C |
| TM050JDHG33-00 | 5.0 inch | 720(RGB)x1280 | 600 cd/m² |
MIPI |
80/80/80/80 | -20 ~ 70 °C |
| TM050RBH01-41 | 5.0 inch | 800(RGB)x480 | 300 cd/m² |
RGB |
70/70/50/70 | -20 ~ 60 °C |
| TM050RDH03-41 | 5.0 inch | 800(RGB)x480 | 250 cd/m² |
RGB |
70/70/50/70 | -20 ~ 70 °C |
| TM050RVHG02-40 | 5.0 inch | 800(RGB)x480 | 330 cd/m² |
RGB |
70/70/50/70 | -20 ~ 70 °C |
| TM055JVZG02-00 | 5.5 inch | 720(RGB)x1280 | 350 cd/m² |
MIPI |
80/80/80/80 | -20 ~ 70 °C |
| TM057JDHP04-30 | 5.7 inch | 720(RGB)x1280 | 450 cd/m² |
MIPI |
85/85/85/85 | -20 ~ 70 °C |
| TM057KBHG01-40 | 5.7 inch | 320(RGB)x240 | 320 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM057KDH01-10 | 5.7 inch | 320(RGB)x240 | 400 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM057KDHG04-00 | 5.7 inch | 320(RGB)x240 | 500 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM057KVHG01-40 | 5.7 inch | 320(RGB)x240 | 340 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM057QDH01-00 | 5.7 inch | 640(RGB)x480 | 400 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM057QDHG03-00 | 5.7 inch | 640(RGB)x480 | 350 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM057QDHG08-00 | 5.7 inch | 640(RGB)x480 | 700 cd/m² |
RGB |
70/70/70/60 | -30 ~ 85 °C |
| TM060JDZG01-00 | 6.0 inch | 800(RGB)x1280 | 380 cd/m² |
MIPI |
85/85/85/85 | -20 ~ 70 °C |
| TM060JVZG02-01 | 6.0 inch | 800(RGB)x1280 | 350 cd/m² |
MIPI |
85/85/85/85 | -20 ~ 70 °C |
| TM062RDH03-08 | 6.2 inch | 800(RGB)x480 | 400 cd/m² |
TTL |
75/75/60/70 | -20 ~ 70 °C |
| TM062RDS01-04 | 6.2 inch | 800(RGB)x480 | 400 cd/m² |
RGB |
75/75/60/70 | -20 ~ 70 °C |
| TM070DDHG03-40 | 7.0 inch | 1024(RGB)x600 | 320 cd/m² |
LVDS |
75/75/70/75 | -20 ~ 70 °C |
| TM070DVHG01-40 | 7.0 inch | 1024(RGB)x600 | 270 cd/m² |
LVDS |
75/75/70/75 | -20 ~ 70 °C |
| TM070JDHG30-00 | 7.0 inch | 1280(RGB)x800 | 400 cd/m² |
LVDS |
88/88/88/88 | -20 ~ 70 °C |
| TM070RBH10-41 | 7.0 inch | 800(RGB)x480 | 350 cd/m² |
RGB |
80/80/60/80 | -20 ~ 70 °C |
| TM070RDH10-40 | 7.0 inch | 800(RGB)x480 | 400 cd/m² |
RGB |
80/80/60/80 | -20 ~ 70 °C |
| TM070RDH13-40 | 7.0 inch | 800(RGB)x480 | 300 cd/m² |
RGB |
80/80/60/80 | -20 ~ 70 °C |
| TM070RDHG23-40 | 7.0 inch | 800(RGB)x480 | 1400 cd/m² |
RGB |
80/80/60/80 | -20 ~ 70 °C |
| TM070RDHG24-00 | 7.0 inch | 800(RGB)x480 | 400 cd/m² |
RGB |
80/80/60/80 | -30 ~ 85 °C |
| TM070RDHG70-00 | 7.0 inch | 800(RGB)x480 | 555 cd/m² |
RGB |
88/88/88/88 | -20 ~ 70 °C |
| TM070RVHG01-01 | 7.0 inch | 800(RGB)x480 | 300 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM070RVHG04-00 | 7.0 inch | 800(RGB)x480 | 1200 cd/m² |
RGB |
80/80/60/80 | -20 ~ 70 °C |
| TM070RVHG50-00 | 7.0 inch | 800(RGB)x480 | 300 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM080SDH01-41 | 8.0 inch | 800(RGB)x600 | 250 cd/m² |
RGB |
70/70/50/70 | -20 ~ 70 °C |
| TM080SDHG02-41 | 8.0 inch | 800(RGB)x600 | 500 cd/m² |
RGB |
70/70/50/70 | -20 ~ 70 °C |
| TM080TDHG01-42 | 8.0 inch | 1024(RGB)x768 | 400 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM084SDHG01-01 | 8.4 inch | 800(RGB)x600 | 350 cd/m² |
LVDS |
70/70/60/70 | -20 ~ 70 °C |
| TM084SDHG02-00 | 8.4 inch | 800(RGB)x600 | 330 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM090DDSG01-01 | 9.0 inch | 1024(RGB)x600 | 500 cd/m² |
LVDS |
70/70/50/70 | -20 ~ 70 °C |
| TM090RDSG01-00 | 9.0 inch | 800(RGB)x480 | 350 cd/m² |
RGB |
70/70/50/70 | -20 ~ 70 °C |
| TM092XDHG01-00 | 9.2 inch | 1920(RGB)x480 | 500 cd/m² |
LVDS |
80/80/70/60 | -30 ~ 85 °C |
| TM097TBHG02-41 | 9.7 inch | 1024(RGB)x768 | 280 cd/m² |
LVDS |
70/60/70/70 | -20 ~ 70 °C |
| TM097TDH01-41 | 9.7 inch | 1024(RGB)x768 | 220 cd/m² |
RGB |
70/70/70/60 | -20 ~ 70 °C |
| TM097TDH02-41 | 9.7 inch | 1024(RGB)x768 | 350 cd/m² |
LVDS |
70/60/70/70 | 0 ~ 50 °C |
| TM097TDHG04-02 | 9.7 inch | 1024(RGB)x768 | 350 cd/m² |
LVDS |
70/70/70/60 | -20 ~ 70 °C |
| TM101DDHG01-00 | 10.1 inch | 1024(RGB)x600 | 450 cd/m² |
LVDS |
80/80/75/80 | -20 ~ 70 °C |
| TM101DDHG04-00 | 10.1 inch | 1024(RGB)x600 | 300 cd/m² |
LVDS |
80/80/75/80 | -10 ~ 50 °C |
| TM101DVHG01-00 | 10.1 inch | 1024(RGB)x600 | 360 cd/m² |
LVDS |
80/80/75/80 | -20 ~ 70 °C |
| TM101JDHG30-00 | 10.1 inch | 1280(RGB)x800 | 500 cd/m² |
LVDS |
85/85/85/85 | -20 ~ 70 °C |
| TM101JDHG32-00 | 10.1 inch | 1280(RGB)x800 | 1000 cd/m² |
LVDS |
85/85/85/85 | -20 ~ 70 °C |
| TM101JDHP01-00 | 10.1 inch | 1280(RGB)x800 | 400 cd/m² |
LVDS |
85/85/85/85 | -10 ~ 50 °C |
| TM101JVHG30-00 | 10.1 inch | 1280(RGB)x800 | 430 cd/m² |
LVDS |
85/85/85/85 | -20 ~ 70 °C |
| TM101JVHG32-00 | 10.1 inch | 1280(RGB)x800 | 850 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM104SBH01-00 | 10.4 inch | 800(RGB)x600 | 300 cd/m² |
LVDS |
70/70/60/70 | -20 ~ 70 °C |
| TM104SDH01-00 | 10.4 inch | 800(RGB)x600 | 400 cd/m² |
LVDS |
70/70/60/70 | -20 ~ 70 °C |
| TM104SDH02-00 | 10.4 inch | 800(RGB)x600 | 400 cd/m² |
LVDS |
70/70/60/70 | -20 ~ 70 °C |
| TM104SDH03-03 | 10.4 inch | 800(RGB)x600 | 400 cd/m² |
LVDS |
70/70/60/70 | -30 ~ 80 °C |
| TM104SDHG30-00 | 10.4 inch | 800(RGB)x600 | 350 cd/m² |
RGB |
70/70/60/70 | -20 ~ 70 °C |
| TM121JDSG10-00 | 12.1 inch | 1280(RGB)x800 | 450 cd/m² |
LVDS |
85/85/85/85 | -20 ~ 70 °C |
| TM121SDS01-05 | 12.1 inch | 800(RGB)x600 | 450 cd/m² |
LVDS |
80/80/65/75 | -20 ~ 70 °C |
| TM121TDSG02-00 | 12.1 inch | 1024(RGB)x768 | 450 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM150TDS50-03 | 15.0 inch | 1024(RGB)x768 | 400 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM150TDSG52-02 | 15.0 inch | 1024(RGB)x768 | 250 cd/m² |
LVDS |
80/80/80/80 | 0 ~ 65 °C |
| TM150TDSG70-01 | 15.0 inch | 1024(RGB)x768 | 300 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM150TDSG71-01 | 15.0 inch | 1024(RGB)x768 | 450 cd/m² |
LVDS |
80/80/80/80 | -20 ~ 70 °C |
| TM150TDSG76-00 | 15.0 inch | 1024(RGB)x768 | 300 cd/m² |
eDP |
80/80/80/80 | -20 ~ 70 °C |
