Product description：

INTRODUCTION:

Model	Diagonal Size	Pixel Format	Luminance	Interface	Viewing Angle	Operating Temperature range
CLAA043JD02CW	4.3 inch	480(RGB)x272	600 cd/m²	RGB	70/70/50/70	-20 ~ 70 °C
CLAA050LA0ACW	5.0 inch	800(RGB)x480	500 cd/m²	RGB	70/70/60/70	-20 ~ 70 °C
CLAA057VC01CW	5.7 inch	640(RGB)x480	220 cd/m²	TTL	70/70/45/55	-30 ~ 85 °C
CLAA070LD0DCW	7.0 inch	800(RGB)x480	500 cd/m²	TTL	70/70/50/70	-30 ~ 85 °C
CLAA070LF0BCW	7.0 inch	800(RGB)x480	450 cd/m²	TTL	75/75/50/70	-20 ~ 70 °C
CLAA070LFA1CW	7.0 inch	800(RGB)x480	450 cd/m²	TTL	75/75/50/70	-30 ~ 85 °C
CLAA070NJ05CW	7.0 inch	1024(RGB)x600	500 cd/m²	LVDS	80/80/60/70	-20 ~ 70 °C
CLAA070NJ07CW	7.0 inch	1024(RGB)x600	600 cd/m²	LVDS	80/80/60/70	-20 ~ 70 °C
CLAA070NQ08XN	7.0 inch	1024(RGB)x600	600 cd/m²	RGB	85/85/85/85	-20 ~ 70 °C
CLAA070WP0BXN	7.0 inch	800(RGB)x1280	380 cd/m²	MIPI	85/85/85/85	0 ~ 50 °C
CLAA080LJ01CW	8.0 inch	800(RGB)x480	450 cd/m²	TTL	75/75/60/70	-20 ~ 70 °C
CLAA080LJA1CW	8.0 inch	800(RGB)x480	600 cd/m²	TTL	75/75/60/70	-30 ~ 85 °C
CLAA080NA12CW	8.0 inch	1024(RGB)x600	600 cd/m²	LVDS	75/75/50/60	-20 ~ 70 °C
CLAA080WK05XN	8.0 inch	1280(RGB)x720	500 cd/m²	LVDS	85/85/85/85	-20 ~ 70 °C
CLAA080WQ05	8.0 inch	800(RGB)x1280	350 cd/m²	MIPI	85/85/85/85	0 ~ 50 °C
CLAA080XA12LE	8.0 inch	1024(RGB)x768	300 cd/m²	LVDS	75/70/75/70	-10 ~ 50 °C
CLAA088WA01XN	8.8 inch	1280(RGB)x480	500 cd/m²	LVDS	85/85/85/85	-20 ~ 70 °C
CLAA090NA06CW	9.0 inch	1024(RGB)x600	500 cd/m²	LVDS	70/70/50/70	-20 ~ 70 °C
CLAA090WK05XN	9.0 inch	1280(RGB)x720	500 cd/m²	LVDS	85/85/85/85	-20 ~ 70 °C
CLAA101ND06CW	10.1 inch	1024(RGB)x600	500 cd/m²	LVDS	70/70/70/50	-20 ~ 70 °C
CLAA104XA02CW	10.4 inch	1024(RGB)x768	400 cd/m²	LVDS	75/75/60/80	-20 ~ 70 °C
CLAA121MQ01CW	12.1 inch	800(RGB)x600	450 cd/m²	LVDS	80/80/70/70	-30 ~ 80 °C
CLAA150XQ01CW	15.0 inch	1024(RGB)x768	450 cd/m²	LVDS	80/80/70/70	-30 ~ 80 °C
CLAA170EC01	17.0 inch	1280(RGB)x1024	450 cd/m²	LVDS	80/80/70/70	-30 ~ 80 °C
CLAA190EB01CW	19.0 inch	1280(RGB)x1024	450 cd/m²	LVDS	85/85/80/80	-30 ~ 80 °C
